hydraulic personal lift table lift platform mobile scaffolding platform

hydraulic personal lift table

This series aluminum alloy hydrauic lift adopt high strength and high quality aluminum alloy sections . Power supply for electric, manual battery,can also install remote control according customer’s requirements. It's a new type of aerial platform lift. The aluminum alloy man platform lifts are equipped with universal casters, flexible. Span on both ends of the frame is adjustable, can be suitable for across different obstacles. On both ends of the frame vertically adjustable and can be used for a certain slope of slope or on the steps.

Advantage of aluminum alloy man platform lift

1.Good balance, easy to operate

2.Small volume,good Passing Ability

3.No noise and air pollution

4. Light weight, easy to move

5. No installation, easy to maintenance

Safety of aluminum alloy man platform lift

1.Install the four support legs

2.equipped with gradienter, Ensure equipment level

3.equipped with emergency decline device

4. High strength guardrail

5. Antiskid and insulated working platform

Main specifications

Model	Lifting height(m)	Load Capacity (kg)	Dimension of table (mm)	Total dimension (mm)	Power(kw)	Net weight(kg)
SJL0.1-6	6	100	550×550×1100	1380×700×1980	0.75	420
SJL0.15-6	6	150	1150×650×1100	1400×800×1980	2.2	480
SJL0.1-8	8	100	600×600×1100	1380×700×1980	0.75	460
SJL0.15-8	8	150	1320×650×1100	1650×700×1980	2.2	520
SJL0.1-10	12	100	600×600×1100	1500×800×2650	0.75	480
SJL0.15-10	12	150	1450×650×1100	1750×800×1980	2.2	560
SJL0.15-12	12	150	1650×650×1100	1950×920×2070	2.2	900
SJL0.15-14	14	150	1550×750×1100	1900×1400×2600	2.2	1000
SJL0.15-16	16	150	1550×650×1100	1900×1200×2700	2.2	700

Pictures

Battery power lift with a drive wheel

16m three-mast lift and 18m four-mast lift

We can put the lift dow if you need min height.

We also can add 4 wheels in side of the lift, then you can move it when the lift is down.

When no electric, you can make the lift down slowly by the down valve

Packaging & Shipping

Company Information

Our Services

1. All the machines will be full tested before shipment

2. The total machine guarantee is 12 moths

3. 24 Hours technical support, email, telephone or video online

4. User-friendly english manual for machine using and maintaining

5. Sereral sets wearing parts will be free for you

Contact us

Amanda Wang Sales Manager E-mail: amandalift(@)jnjinchuang.com & amandalift(@)hotmail.com Mobile:86-15005311496 Skype:qqmary007 Company: Jinan Jinchuang Machinery Manufacturing CO., LTD ADD: Jibei Development Zone, Jinan City, Shandong Province, ChinaWeb: http://lifting.en.alibaba.com/

-Wide chassis makes the lower part of the Equipment which can bear the load balance to enhance stability.
-355/55D625 Solid Tyre, hydraulic personal lift table lift platform mobile scaffolding platform can keep stable not only in a variety of complex conditions but also enhance the ground friction then mobile platform lift is more stable in operation and climbing easier.
-mobile platform lift The steering system adopts double oil cylinder and Hydra steering system with 40Cr steering linkage to ensure the same direction.
-Floating leveling device will start automatically when the device encountered under the condition of uneven groundto ensure the balance of equipment hydraulic personal lift table lift platform mobile scaffolding platform with slope of 6 degrees then strengthen the safety and adaptability.
DFGXSDFGBA
-360°continuous rotationwith 50Cr rotary support
-Emergency safety pump. mobile platform lift The operator can use emergency safety pump to fall safelywhen the equipment is working at high altitude which can not be down.
-Constant pressure pump of Danfoss USA or Rexroth Germanit avoid oil leakage caused by gear pump damage in long -term construction
-hydraulic personal lift table lift platform mobile scaffolding platform of centralized electric control box is used to ensure the safety of equipment operation
-Ground control console and platform control console the former has a large screen display with self diagnostic screen without connected mobile platform lift to the computerthen customers can easily understand the calibration status of equipment and parameters which is convenient debugging and testing.
-Controller of IFM Germany can enhance system stability
-Turntable safety lockto avoid the damage in the transport mobile platform lift and maintenance of arm rotation
-Swing-out engine bracket - provide the world industry closest to the engine design easy maintenance and repairs.
-Glass fiber hydraulic personal lift table lift platform mobile scaffolding platform steel cover make the whole equipment nice and durable
